Плеер для ONKYO DP-S1A  выпущен для внутреннего рынка Японии. Не путать эту модель с ONKYO DP-S1B (более простая версия). В Европе и США ONKYO DP-S1A  продавался как модель ONKYO PD-S10. Русифицированное меню.

Покупался в Японии за 500 USD + фирменный чехол 50 USD. Практически не использовался. В идеальном состоянии as new, установлена заводская защитная пленка. Полный комплект.

Шикарное звучание на двух ЦАП SABRE ES9018C2M, нативная поддержка DSD 5.6 MHz/2.8 MHz , MQA, и 192 kHz/32-bit FLAC/WAV Hi-Res. Этот плеер легко переиграл Astell&Kern AK 100II. Продаю, так как не использую.

PREMIUM AUDIO FEATURES

• Twin ESS SABRE ES9018C2M DACs and SABRE ES9601K amplifiers

• Fully balanced L/R circuit layout and separate audio and processing boards

• Customized high-current, high-capacity conductive polymer chip capacitors

• Rigid one-piece machined aluminum chassis and triple-thickness battery case

• Reinforced anti-resonant volume mechanism and headphone output assembly

• Supports native DSD 5.6 MHz/2.8 MHz playback, MQA, and 192 kHz/32-bit FLAC/WAV Hi-Res Audio formats

• BTL (Bridge-Tied Load) and ACG (Active Control Ground) balanced playback

• 32-bit DSP and two dedicated clocks for 44.1 kHz and 48 kHz signals

• 192 kHz/32-bit upsampling function for standard audio sources

• 3-stage gain (Low/Normal/High) to suit 16–600-ohm headphones

• 10-band equalizer with 6 factory presets and 3 user presets

• Three selectable digital filters (Sharp/Short/Slow)

• 7-Step Lock Range Adjustment (Wide/Normal/Narrow)

STORAGE & CONNECTIVITY

• 528 GB storage: 16 GB (Internal) and 2 x 256 GB microSD Card slots

• Built-in 5 GHz/2.4 GHz Wi-Fi

• Built-in Deezer HiFi and TIDAL lossless album streaming services and TuneIn internet radio

• Direct Hi-Res Audio downloads via Onkyo Music without a PC

• Bluetooth technology connects supported stereos and headphones

• 3.5 mm  headphone/AUX/line-level output

• 2.5 mm  balanced audio headphone output

• USB/OTG terminal for recharging, audio transfer, and digital audio output to supported components

INDUSTRIAL DESIGN & USER INTERFACE

• Bright 2.4-inch 320 x 240-pixel touchscreen

• Customizable home-screen tiles for fast and easy GUI navigation

• Scroll bars and Index Display for fast navigation of large music libraries

• External volume wheel and playback buttons (HOLD, Play/Pause, Skip/Scan)

• Supports Onkyo DapController for iPad, iPhone, and Android

• Luxury high-texture hairline back-panel finish

• Up to 15 hours play-time via internal rechargeable battery

• Onkyo X-DAP Link software for Window

SPECIFICATIONS

Power Output

150 mW + 150 mW (Balanced, 32 ohms)

75 mW + 75 mW (Unbalanced, 32 ohms)

THD+N (Total Harmonic Distortion + Noise)  Less than 0.006%

Frequency Response 20 Hz–80,000 Hz

Signal-to-Noise Ratio 115 dB or above

Headphone Impedance

16 Ohms–300 Ohms (Unbalanced)

32 Ohms–600 Ohms (Balanced)

DAC Section

DAC Type SABRE ES9018C2M

Maximum Resolution 192 kHz/32-bit

Clocking Devices  (44.1 kHz/48 kHz)

General Power Supply

Rechargeable 1,630 mAh

lithium-ion battery

Dimensions (W x H x D)

63 x 94 x 15 mm (2.5 ̋ x 3.7 ̋ x 0.6 ̋ )

Weight 135 g (4.76 oz.)

Dimensions (W x H x D)

Single Carton

Dimensions (W x H x D)

125 x 140 x 39 mm (4.9 ̋ x 5.5 ̋ x 1.5 ̋ )

Weight

270 g (9.5 oz.)

Supplied Accessories

• Micro USB to USB Type-A cable

• Screen protector films (x2)

• Quick Start Guide • Safety information and precautions
